Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: WISION/OEM
  • Model Number: WS-M5V12
  • Type: Digital Camera
  • Style: IP Module/IP Board Camera
  • Sensor: CMOS
  • Technology: NetWork
  • Special Features: Megapixel IP Module/ IP Board Camera
  • 720P resolutions: output complete real-time 720P images
  • H.264 Compression: compatible with various smart Phone operating system
  • size: 38mm x 38mm
  • Day&Night: Electronic or ICR
  • Min.Lux: Color: 1Lux F1.2, B/W: 0.1LuxF1.2

Packaging & Delivery

Packaging Details Standard Package , 1pc/color box . 40pcs/Ctn
Delivery Time 2-3days

Hot selling 1080P HD waterpfoo ip camera p2p,cloud service, oem ip camera module







WS-M5V12



Features
* Up to 720P resolutions; output complete real-time 720P images;
* H.264 Compression, multi streaming, mobile surveillance; compatible with various smart Phone operating system ;
* Support Wision Unique Video Release System, LAN and Internet(ADSL,Cable Modem);
* Multi users browsing at one time; system online upgrade;
* Support two-way voice intercom and broadcast, Alarm I/O, RS485 control;
* AWB and AGC and CVBS Video output;
* Abnormal auto-recovery, network interrupt auto-connected
* 38mm x 38mm standard size design, compact appearance, simple structure; suitable for a variety of housing, easy to install
* Embedded RTOS, high-performance DSP, pure hardware compression,and longer life;
* Provide centralized management client freely; Provide CS platform for large scale system which support various storage platform.


Parameters
Parameters
ProcessorTI Single Chip SOC
Image Sensor1/4" 1.0M Pixels CMOS
Min.LuxColor: 1Lux  F1.2, B/W: 0.1LuxF1.2
IR-CutSupport
Shutter Control1/5-1/50,000 sec
LensC/CS
Auto IrisDC Drive
Day&NightElectronic or ICR
Compression
Video CompressionH.264/M-JPEG
Bite Rate64 Kbps~12Mbps
Audio CompressionG.711
Max. Size1280×720
Resolution& Frame Rate30fps 1280×720(720P)
30fps 640×352(VGA)
30fps 352×192(QVGA)
Image SettingBLC,Saturation,Brightness,Contrast,Sharpness,Gain,Multi-Streams,Bit Rate, Frame Rate are adjustable through Client software or IE
Network
StorageSD/SDHC 32G
Intelligent AlarmMotion,Interruption Network,Alarm I/O
Network ProtocolSupport HTTP,DHCP,UDP,RTP/RTSP,NTP,FTP
Access ProtocolONVIF,PSIA
General FunctionsA Reset Button, Anti-flash, Multi-stream, Password-protected, OSD Technology
Interface
Audio Input1ch,Level:3.3Vp-p,12dB Gain Amplification, Audio Input(ADC),WDR:70dB,Sample Rate:8kHZ
Audio Output1ch, Audio Signal Output WDR:70dB, Connecting Amplifier
Network InterfaceRJ45-10/100M self adaptive Ethernet,RS485
Alarm Input1ch
Alarm Output1ch
Video OutputAn Analog Video Output, Support CVBS Standard, PAL / NTSC Optional
Power SupplyDC12V/POE
